Revere Grey 4200mm 3+3

Part of the Revere Grey Range | External Bi-Fold Doors

Aperture width: 4200mm (3+3)
Door configuration: 3+3
Outer Frame Size: 4190 x 2090mm (w x h)
Brickwork Opening: 4200 x 2100mm (w x h)
Product Code: 999420033
  • Door FinishAnthracite Grey
  • Door Leaf Thickness70mm
  • Door Set ConstructionAluminium
  • Door Set U-Value1.5 U-Value


Save £222.5


Price includes VAT and delivery!

Made to order

Delivery in 4 - 5 weeks

SKU: 999420033 Categories: , ,


Grey aluminium bifolds are the current must-have feature piece for any project, from large developments through to small scale renovations. Sleek matt-grey lines compliment traditional properties as well as more contemporary builds, bringing a touch of subtle class to your home. The 70mm aluminium surrounds for each door offer superb structural strength without the same weight as timber sets, while the thermal break and double glazed units ensure these doors surpass the thermal efficiency benchmarks set by British building regulations.

Fully finished with an Anthracite Grey RAL 7016M  powder coating system, these aluminium bifolds will last and last without the need for regular finish maintenance, keeping your home effortlessly stylish. The Revere also has two threshold options to suit your project: one standard, and one for partially rebated installations.

This 4.2m set is made up of 6 doors. After placing your order, we will contact you to discuss your threshold choice and whether you want your set to be left or right opening.

Please note the glazing for this set is supplied unfitted to allow easy installation of the framework. This is then fitted during the assembly process.

If being installed within 2 miles of salt water, this set will require a marine grade coating. If this applies to your property, please contact us for a quote.

At least two able-bodied people must be available on site to assist the driver at the point of delivery in order to safely offload the product.

Photos of customer installations are for illustrative purposes only.

Technical details

Aluminium with Thermal Break
Anthracite Grey – RAL 7016M
Aluminium Profiles
Smarts Visofold 1000
28mm Toughened Low E Double Glazed Unit
Centre Pane U-Value
Overall U-Value
Door Thickness
High security bottom-hung concealed carriers
Security Features
High security hardware and multi-point locking system as standard
This product is fully compliant with British building regulations, including Part J and Part L
10 years against manufacturing, subject to correct installation
Daily Access Door
Opening Direction
Left or Right
Supplied As
Kit Form
Hanging Type
Bottom Hung
